Sublistar Star IV 60R Roll To Roll UV DTF Printer

$23,809.98
SKU:
Availability : In Stock Pre order Out of stock

Technical Highlights:

  • Print Head: Epson XP600 print heads.
  • Print Size: 600mm.
  • Print Speed: 12m2/h.
  • Ink Type: ECO-UV Curing Ink.

Top Features:

  • The curved surface plane can be transferred, and the transfer effect is good.
  • Support 360 ° rotation printing, fully meeting the needs of personalized customization.
  • Printing with a sense of hierarchy, 3D relief sense of visibility, and tangibility.
  • Efficient printing, stable output, cut-resistant, colorfast.

Style: 3*i3200

3*i3200
4*i3200
Overview

STAR-IV 60R UV DTF Printer Overview

The Star IV 60R Roll To Roll UV DTF Printer allows one person to print individual crystal labels. It also supports 360 °printing with embossed texture, which can be widely transferred on all kinds of hard surfaces.

Features & Benefits

  • 4 Colors + White & Varnish Are More Expressive

Equipped with 6 ink tanks, 4 colors of ink can be installed. It can finish exquisite shading with high precision. In addition, using white ink and clear varnish, it has rich expressive power and fulfills various needs.

  • Print Varnish And 3D Relief Effects

The three nozzles of white varnish inkjet at the same time can produce D relief and a multi-layer transparent bump effect, including an amazing varnish glossy effect and a matte finish.

  • Electric Cylinder Fixture, Support 360° Rotation Printing

A cylindrical fixture is installed on the platform, which can realize the printing of cylindrical products such as thermos cups and mugs and supports printing with a diameter of 30–120 mm to meet the needs of personalized customization.

  • High-Performance Inks For A Variety Of Applications

It is an eco-friendly UV ink with excellent color development and color reproducibility. It is cured by ultraviolet radiation. In addition to bright colors and style, it also has strong adhesion.

Applications Of Roll UV Printer

Different customers will use UV printers to print different products. Subristar roll UV printer is mainly used for toys, mobile phone shells, PVC boards, acrylic, stainless steel, background walls, etc. What industries are Roll UV printers used in? For example, toy industry, advertising and signage market, home decoration and furniture market, personalized gift market, etc.





Star IV 60R Printing Process

  • Design Pattern

Use Photoshop, Illustrator, or other software to design your pattern.

  • Print Your Design On AB Film

Adjust the printer parameters in the RIP software and use our UV DTF printer and ink to print your pattern on AB film.

  • Cutting

Cut UV DTF crystal labels

  • Transfer Film On Products

Stick the UV DTF sticker on the substrates, repeat pressing the pattern, and then slowly peel the film off and finish.





INCLUDED WITH YOUR PURCHASE:

  • STAR-IV 60R Flatbed UV printer
  • UV DTF A film: 1 roll (300mm/600mm*100m)
  • UV DTF B film: 1 rolls (300mm/600mm*100m)
  • Sublistar UV DTF Rip Software
  • Lifetime Technical Support
  • Limited 2-year warranty for machine

BONUS: Sublistar UV DTF Instructional Video

BONUS: ICC Profile for SUBLISTAR UV Inks ONLY

Specifications

Product Specifications - Star IV 60R UV DTF Printer

BrandSublistar
Item ModelUV STAR IV-60R
Print NozzleUsing epson print head, including 400 nozzles/ row*8*lines*4, high quality up to 1800dpi
Print Accuracy/Speed4pass:12m2/h 6pass:8m2/h 8pass:5m2/h
InkSortUV
Water based ink/ Eco solvent ink, Water rased ink; Dye ink, Sublimation ink
Capacity5 Colors:! .5L*7/color
MediaMaximum Width620mm
Thickness1.5mm to 6mm adjustable
Max Roll Weight20KG
SortUV-DTF
High Printing QualityThree intelligent eclosion print function; VSD technology
Media HeaterPre/Post Heater (Can be controlled separately)
Print InterfaceUSB 2.0
RIP SoftwareMaintop6.0, Photoprint, Print Factory
VoltageAC110V+/- 10%. AC220V+/-10%、50/60+/HZ
Operating EnvironmentsTemperature: 20°C-35°C; Humidity:35%RH-65%RH
Power200W for drawing and 450W for heating in front, middle and back
Dimensions Of Printer(LxWxH)1785x790x 1613mm
Dimensions Of Packing(LxWxH)2100 x 970 x 730mm
Height Of Worktable1062mm
Net Weight200KG
Gross Weight220KG

Epson F1080(XP600) Print Head

UV STAR IV-60R using Epson F1080 print heads. It is an economical printhead, designed as a water-based head. The price is very cheap, the stability is moderate and it is widely accepted by the market. It is mainly used for small environmentally friendly solvent ink printers or roller UV printers.

epson-xp-600



ModelXP600/F1080
Ink TypesEco-solvent ink, UV
Size(width x depth x height)(mm)84.9×57.2×42.6
Weight(g)60
Nozzle Numbers1080
Length Between Nozzles(inch)180
Nozzle Row6row
Max color/head6colors(180dpi/color)
Resolution180npi/row 360dpi/2row
Effective Printing Width(mm)25.4
Jet Frequency(kHz)46(single dot),11.52(multi dot)
Ink Drops(pl)4.5-9-20-40
Ink Viscosity(mPa.s)3~5
