Sublistar STAR IV A3/450 DTF Printer & Shaker
Customer Reviews
Product details
Print Head: F1080 print heads
Max Print Size: 300mm Print Width
Print Speed: 3-8m2/h
Ink Type: CMYK+W
Feature
DTF-A3 STAR Ⅳ is a new generation of the digital revolution, creating a new digital dtf film printing process. The function of low maintenance time can be realized. The maximum printing width is 300mm. Max print speed up to 8m2/h.
New Feature
DTF STAR series has greatly improved printing technology: Automatic In-Line moisturizing system, Front, middle, and rear heating devices, and Simultaneous White and full color. Improving the machine’s stability, prolonging machine parts’service life, and making the machine more efficient.
| This is the automatic in-line moistening system, which can keep the printer nozzle in the best working state. |  |
| The worktable of the new generation DTF printer is equipped with heating devices in the front, middle and rear directions, which can ensure that the printed pattern becomes dry instantly. |  |
| It is an economical printhead, designed as a water-based head. The price is very cheap, the stability is moderate and it is widely accepted by the market. It is mainly used for small environmentally friendly solvent ink printers or roller UV printers. |  |
| The coverage of color ink and white ink is very accurate, and there is no white edge. In addition, it has wide color gamut and gradient color. The effect is excellent. |  |
Epson F1080(XP600) Print Head |
Model | XP600/F1080 |
| Mini300ProMax using Epson F1080 print heads. It is an economical printhead, designed as a water-based head. The price is very cheap, the stability is moderate and it is widely accepted by the market. It is mainly used for small environmentally friendly solvent ink printers or roller UV printers. | Ink Types | Eco-solvent ink, UV |
| Size(width x depth x height)(mm) | 84.9×57.2×42.6 | |
| Weight(g) | 60 | |
| Nozzle Numbers | 1080 | |
| Length Between Nozzles(inch) | 180 | |
| Nozzle Row | 6row | |
 |
Max color/head | 6colors(180dpi/color) |
| Resolution | 180npi/row 360dpi/2row | |
| Effective Printing Width(mm) | 25.4 | |
| Jet Freqency(kHz) | 46(single dot),11.52(multi dot) | |
| Ink Drops(pl) | 4.5-9-20-40 | |
| Ink Viscosity(mPa.s) | 3~5 |
Machine Parameter
| A3 STAR IV DTF Printer | ||
| Model | DTF-A3 STAR IV | |
| Print Nozzle | 2 XP600 Printheads | |
| Precision / Print speed | 4pass: 8m2/hour | |
| 6pass: 5m2/hour | ||
| 8pass: 3m2/hour | ||
| Ink | DYE\DTF\ Sublimation | |
| Maximum Width | 300mm | |
| Print Media | PP Sythentic Paper \ PET Film \ UV DTF | |
| Print Interface | RJ45 Cable interface | |
| RIP Software | Hemo Driver / Maintop6.1 / Photoprint / Print Factory | |
| Power | AC110V / AC220V / 50/60HZ | |
| Operating Environments | Temperature: 20℃-35℃, Humidity: 35%RH-65%RH | |
| Dimensions of Printer (L x W x H) | 980(L) x 630(W) x 530(H) mm | |
| Dimensions of Packing (L x W x H) | 1100(L) x 680(W) x 760(H) mm | |
| Net Weight | 80KG | |
| Gross Weight | 120KG | |
| DTF Powder Shaker and Dryer（S8） | ||
| Model | S8-A3 | |
| Operation Mode: | PLC Touch Screen | |
| Oven Temp: | Adjustable | |
| Voltage: | 110v/220v, 3phase, 60Hz | |
| Power: | 2kw | |
| Shaker Size: | 1500mm L x 720mm W(with Air Filter) x 670mm H | |
| Shaker Weight: | 100kg | |
Customer Reviews
1 Year Warranty
Within 1 year from the date of purchase, if the machine has non-man-made damage, you can enjoy free warranty service.
DTF Starter Kit
Film: 0.6m*100m/0.3m*100m roll size (cold peel) Powder: 2 kg (4.4 lbs) Ink: 1000ml*6 (c,m,y,k+w)
Rip Software
Nam libero tempore, cum soluta nobis est Buy a machine and you will get a $500 worth of rip softwarefor free. CADlink, SAI FLEXI, Acrorip, MainTop for option.
Online Technical Support
The expert team will serve you online and solve any problems you encounter for free.
| All Services In One Place |
Onboarding Service We offer a dedicated team of professionals to share video/screen share to ensure you get set up and print right away. |
|
On/offline Training Support We provide important after-sales support and training, free online training, and on-site coaching to customers worldwide. There are several video programs available as training resources. |
|
|
"Heads and All" Warranty We provide a 6-month free warranty for print heads, and all printers are backed by a standard 24 months. You can also extend the warranty for peace of mind. |
